带自动换刀装置和十字铣刀的小型数控车床图纸下载,该图纸类型属于机械设备、加工机械图纸,图纸大小208.27M,图纸格式为step,pdf,图纸软件为STEP,可供设计参考。

带自动换刀装置和十字铣刀的小型数控车床
首页>图纸库>机械设备>加工机械2022-12-24报告错误错误问题可与客服联系，感谢您的支持！[获取免费下载]分享好友可以免费下载哦！1
0
316
图纸预览图
图纸预览图
图纸预览图
图纸预览图
图纸预览图
图纸预览图
图纸预览图
图纸预览图
图纸预览图
图纸预览图
图纸描述
带自动换刀装置和十字铣刀的小型数控车床图纸下载,该图纸类型属于机械设备、加工机械图纸,图纸大小208.27M,图纸格式为step,pdf,图纸软件为STEP,可供设计参考。
下载需要10金币 推广可免费下载
立即下载 收藏
图纸信息
图纸ID ：561556
文件大小：208.27M
所需金币：10
图纸参数：可编辑，包含特征参数
图纸分类：机械设备
图纸格式：step,pdf
软件版本：STEP
作者
席驼
已分享: 份作品
作者头像
关注
文件列表
#文件名称大小
1软件图标11 LatheAssembly.iges239.22M
2软件图标9 LatheAssembly.step245.01M
3软件图标9 LatheATCAssembly.step99.47M
4软件图标9 LatheBaseAssembly.step37.98M
5软件图标9 LatheCrossBaseAssembly.step27.28M
6软件图标9 LatheCrossSlideAssembly.step41.52M
7软件图标9 LatheTailstockAssembly.step15.64M
8软件图标18 SourceLinks.pdf41.16K
9软件图标28 300mmRailAssembly.FCStd1.33M
10软件图标28 500mmRailAssembly.FCStd343.33K
11软件图标28 800mmRailAssembly.FCStd154.24K
12软件图标28 ATCAssembly.FCStd9.76M
13软件图标28 ATCBackPlateAssembly.FCStd902.23K
14软件图标28 ATCBottomPlateAssembly.FCStd232.41K
15软件图标28 ATCFacePlateAssembly.FCStd4.16M
16软件图标28 ATCFrontPlateAssembly.FCStd805.89K
17软件图标28 ATCLeadNutAssembly.FCStd85.59K
18软件图标28 ATCLockMotorAssembly.FCStd771.43K
19软件图标28 ATCPinBlockAssembly.FCStd41.88K
20软件图标28 ATCSideAAssembly.FCStd76.30K
21软件图标28 ATCSideBAssembly.FCStd332.75K
22软件图标28 ATCTopPlateAssembly.FCStd3.51M
23软件图标28 BallNutAssembly.FCStd58.94K
24软件图标28 BallNutMountAssembly.FCStd77.90K
25软件图标28 BallScrewFixedEndAssembly.FCStd169.97K
26软件图标28 BallScrewFloatingEndAssembly.FCStd81.50K
27软件图标28 BaseACMEGuideAssembly.FCStd29.74K
28软件图标28 BaseACMENutMountAssembly.FCStd179.94K
29软件图标28 BaseAssembly.FCStd2.05M
30软件图标28 BaseMotorMountAssembly.FCStd592.28K
31软件图标28 BaseSaddleGuideAssembly.FCStd561.77K
32软件图标28 BaseSaddlePlateAssembly.FCStd1.94M
33软件图标28 BaseSaddleStepperMountAssembly.FCStd238.93K
34软件图标28 CrossSlideACMENutMountAssembly.FCStd147.33K
35软件图标28 CrossSlideAssembly.FCStd13.65M
36软件图标28 CrossSlideLeadScrewGuideAssemby.FCStd27.81K
37软件图标28 CrossSlideMotorMountAssemby.FCStd348.90K
38软件图标28 CrossSlidePlateAssembly.FCStd7.51M
39软件图标28 CrossSlideVerticalBracePlateAssembly.FCStd64.89K
40软件图标28 DiscBrakeCaliperAssembly.FCStd358.03K
41软件图标28 DiskBrakePulleyAssembly.FCStd347.74K
42软件图标28 Dual500mmRailAssembly.FCStd681.70K
43软件图标28 EncoderAssembly.FCStd125.18K
44软件图标28 HeadstockRiserAssembly.FCStd1.41M
45软件图标28 HGR20GuideBlockAssembly.FCStd198.87K
46软件图标28 HGR20x300mmRailAssembly.FCStd63.79K
47软件图标28 HGR20x500mmRailAssembly.FCStd103.75K
48软件图标28 LatheAssembly.FCStd20.51M
49软件图标28 LeadScrewCoverAngleAssembly.FCStd37.02K
50软件图标28 SpindleMountPlateAssemlby.FCStd203.20K
51软件图标28 SteelBaseAssembly.FCStd2.73M
52软件图标28 StopBlockAssembly.FCStd25.67K
53软件图标28 TailstockAssembly.FCStd1.17M
54软件图标28 TailStockRiserPlate1Assembly.FCStd92.85K
55软件图标28 TailStockRiserPlate2Assembly.FCStd93.17K
56软件图标28 TailStockRiserPlate3Assembly.FCStd92.45K
57软件图标28 TailStockRiserPlate4Assembly.FCStd36.90K
58软件图标28 TailStockRiserPlate5Assembly.FCStd33.41K
59软件图标28 test.FCStd2.22M
60软件图标28 TieWrapMountAssembly.FCStd56.21K
61软件图标28 Z300mmRailAssembly.FCStd562.15K
62软件图标28 ZACMENutMountAssembly.FCStd152.02K
63软件图标28 ZMotorMountAssemby.FCStd344.46K
64软件图标28 ZPlateAssembly.FCStd1.99M
65软件图标28 ZPlateMotorMountPlate1.FCStd44.88K
66软件图标28 ZPlateMotorMountPlate2.FCStd68.20K
67软件图标28 ZPlateMotorMountPlate3.FCStd71.53K
68软件图标28 ZPlateMotorMountPlate4.FCStd86.30K
69软件图标28 ZPlateMotorMountPlate5.FCStd45.17K
70软件图标28 10mmBoringBar.FCStd303.36K
71软件图标28 10x0.5AluminumSpacer.FCStd12.34K
72软件图标28 140mmBrakeDisc.FCStd245.79K
73软件图标28 1605BallNut.FCStd45.03K
74软件图标28 1605BallNutMountBlock.FCStd41.81K
75软件图标28 1605x350mmBallScrew.FCStd16.67K
76软件图标28 1605x400mmBallScrew.FCStd14.95K
77软件图标28 170KVBrushlessDCMotor.FCStd256.68K
78软件图标28 1_2-10ACMEAnti-BacklashNut2.FCStd209.88K
79软件图标28 1_2-10ACMEJamNut.FCStd37.57K
80软件图标28 1_2-10ACMEThreadedRod1.FCStd5.09K
81软件图标28 1_2-10ACMEThreadedRod2.FCStd5.12K
82软件图标28 1_2-10ACMEThreadedRod3.FCStd5.11K
83软件图标28 1_2-13x2SwivelLevelingFoot.FCStd283.56K
84软件图标28 1_2NarrowFlatWasher.FCStd9.61K
85软件图标28 1_2ShaftCollar.FCStd104.46K
86软件图标28 20Tooth3MPulley.FCStd171.12K
87软件图标28 22Tooth3MPulley.FCStd201.57K
88软件图标28 24Tooth3MPulley.FCStd197.83K
89软件图标28 3_8LathePartingTool.FCStd412.87K
90软件图标28 3_8lathetool.FCStd322.71K
91软件图标28 3_8lathetool2.FCStd335.69K
92软件图标28 40Tooth3MPulley.FCStd452.33K
93软件图标28 40ToothGt2Pulley.FCStd236.82K
94软件图标28 530112mmDoubleRowRadialContactBearing.FCStd31.75K
95软件图标28 6001Bearing.FCStd33.62K
96软件图标28 608Bearing.FCStd24.33K
97软件图标28 60Tooth3MPulley.FCStd307.71K
98软件图标28 60Tooth3MPulley2.FCStd580.80K
99软件图标28 6mmx10mmCylindricalMagnet.FCStd5.06K
100软件图标28 6PosAviationConnector.FCStd447.36K
101软件图标28 70x10ElectroMagnet.FCStd37.12K
102软件图标28 750WBLDCMotor.FCStd583.88K
103软件图标28 80Tooth3MPulley.FCStd391.15K
104软件图标28 80ToothGT2Pulley.FCStd323.84K
105软件图标28 8mmPillowBlockBearing.FCStd224.75K
106软件图标28 8mmx64Shaft.FCStd5.09K
107软件图标28 AntiBacklashNut.FCStd310.25K
108软件图标28 ArduinoMega.FCStd3.32M
109软件图标28 ATCSpindleShaft.FCStd29.13K
110软件图标28 ATCToolWedge.FCStd75.14K
111软件图标28 BF12BallScrewFloatingBearingEnd.FCStd262.98K
112软件图标28 BK12BallScrewFixedBearingEnd.FCStd417.08K
113软件图标28 BLDCMotor.FCStd1.58M
114软件图标28 BrakePad.FCStd71.73K
115软件图标28 BRH5055140KVBrushlessMotor.FCStd202.63K
116软件图标28 BrushlessDCMotor.FCStd732.96K
117软件图标28 BTS7960H-BridgeModule.FCStd365.42K
118软件图标28 CableChain.FCStd563.37K
119软件图标28 CenterDrill.FCStd39.85K
120软件图标28 ClampBar.FCStd534.75K
121软件图标28 ClampBarSlider.FCStd266.35K
122软件图标28 DelrinTR8AntiBacklashNut.FCStd86.59K
123软件图标28 DrillBit.FCStd265.52K
124软件图标28 Encoder.FCStd53.00K
125软件图标28 ER16ColletChuck.FCStd714.68K
126软件图标28 F8-16MThrustBearing.FCStd35.60K
127软件图标28 FlexCoupling.FCStd1.36M
128软件图标28 GT2TimingBeltforEncoder.FCStd13.91K
129软件图标28 HGR20GuideBlock.FCStd143.86K
130软件图标28 HGR20HolePlug.FCStd4.64K
131软件图标28 HGR20x300mmRail.FCStd43.71K
132软件图标28 HGR20x400mmRail.FCStd15.06K
133软件图标28 HGR20x500mmRail.FCStd46.77K
134软件图标28 HGR20x800mmRail.FCStd48.02K
135软件图标28 HTD3M24ToothPulley10mmBore.FCStd64.85K
136软件图标28 HTD3M24ToothPulley6mmBore.FCStd65.69K
137软件图标28 HTD3M750x15mmTimingBelt.FCStd19.75K
138软件图标28 HTD3MTimingBeltForATC.FCStd13.97K
139软件图标28 HTD3MTimingBeltForBLDCMotor.FCStd13.85K
140软件图标28 HTD3MTimingBeltForCrossSlide.FCStd14.30K
141软件图标28 HTD3MTimingBeltForER20Spindle.FCStd14.49K
142软件图标28 L298NH-Bridge.FCStd108.72K
143软件图标28 LatheToolHolder.FCStd248.37K
144软件图标28 LimitSwitch.FCStd122.31K
145软件图标28 M12HexNut.FCStd10.20K
146软件图标28 M12InductiveProximitySensor.FCStd81.06K
147软件图标28 M12InductiveProximitySensor2.FCStd81.06K
148软件图标28 M12InductiveProximitySensor3.FCStd81.05K
149软件图标28 M12NarrowWasher.FCStd3.87K
150软件图标28 M2x10PhillipsPanHeadScrew.FCStd34.92K
151软件图标28 M3.5x10HexSocketButtonHeadScrew.FCStd20.57K
152软件图标28 M3x10HexSocketButtonHeadScrew.FCStd9.74K
153软件图标28 M3x5HexSocketCapScrew.FCStd10.11K
154软件图标28 M3x6HexSocketButtonHeadScrew.FCStd9.72K
155软件图标28 M3x6ThreadedSpacer.FCStd40.74K
156软件图标28 M4HexNut.FCStd10.27K
157软件图标28 M4NarrowWasher.FCStd3.91K
158软件图标28 M4x12HexSocketFlatHeadScrew.FCStd9.87K
159软件图标28 M4x16HexSocketCapScrew.FCStd10.14K
160软件图标28 M4x20HexSocketCapScrew.FCStd10.14K
161软件图标28 M4x20HexSocketFlatHeadScrew.FCStd9.88K
162软件图标28 M4x8HexSocketCapScrew.FCStd10.22K
163软件图标28 M4x8HexSocketFlatHeadScrew.FCStd9.85K
164软件图标28 M5-25mmHexSocketFlatHeadScrew.FCStd9.98K
165软件图标28 M5HexNut.FCStd10.37K
166软件图标28 M5NarrowWasher.FCStd3.91K
167软件图标28 M5x16HexSocketCapScrew.FCStd10.17K
168软件图标28 M5x16HexSocketFlatHeadScrew.FCStd9.99K
169软件图标28 M5x20HexSocketCapScrew.FCStd10.17K
170软件图标28 M5x30HexSocketCapScrew.FCStd10.30K
171软件图标28 M5x35HexSocketCapScrew.FCStd10.31K
172软件图标28 M5x40HexSocketCapScrew.FCStd10.30K
173软件图标28 M6Washer.FCStd3.93K
174软件图标28 M6x16HexSocketCapScrew.FCStd10.14K
175软件图标28 M6x16HexSocketFlatHeadScrew.FCStd9.99K
176软件图标28 M6x25HexSocketCapScrew.FCStd10.16K
177软件图标28 M8AllthreadRod.FCStd5.10K
178软件图标28 M8NarrowWasher.FCStd3.92K
179软件图标28 M8ThinHexNut.FCStd10.36K
180软件图标28 M8x45CarriageBolt.FCStd23.68K
181软件图标28 MagneticNCswitch.FCStd83.53K
182软件图标28 MegaTerminalShield.FCStd706.53K
183软件图标28 MF104ZZ4x10x4Bearing.FCStd38.85K
184软件图标28 MiniArduinoMega256.FCStd2.79M
185软件图标28 NEMA17StepperMotor.FCStd305.75K
186软件图标28 Nema2341mmFrameStepperMotor.FCStd476.61K
187软件图标28 Nema2375mmFrameStepperMotor.FCStd459.22K
188软件图标28 PerfBoard.FCStd699.78K
189软件图标28 PowerSupply.FCStd773.23K
190软件图标28 R8-2RSBearing.FCStd30.05K
191软件图标28 RubberGrommet.FCStd15.15K
192软件图标28 StepperDriver.FCStd287.86K
193软件图标28 TailStock.FCStd155.80K
194软件图标28 TailStock2.FCStd457.64K
195软件图标28 TB6560StepperDriver.FCStd893.50K
196软件图标28 TB6600Driver.FCStd2.38M
197软件图标28 TieWrapSaddle.FCStd168.86K
198软件图标28 WormdriveMotor.FCStd143.24K
199软件图标28 Xl-14Pulley.FCStd62.01K
200软件图标28 80mmAluminumHeadstockAssembly.FCStd627.96K
201软件图标28 80mmHeadstockAssembly.FCStd157.34K
202软件图标28 80mm3JawChuck.FCStd177.02K
203软件图标28 AluminumSpindleHousing.FCStd105.60K
204软件图标28 Bearing.FCStd34.35K
205软件图标28 BearingHousing.FCStd29.39K
206软件图标28 ER40Collet.FCStd177.48K
207软件图标28 Housing.FCStd614.78K
208软件图标28 M6HexSocketCapScrew.FCStd10.15K
209软件图标28 M8HexSocketCapScrew.FCStd10.46K
210软件图标28 ShaftNut.FCStd71.83K
211软件图标28 ShaftNutLockWasher.FCStd18.77K
212软件图标28 Spindle.FCStd624.05K
213软件图标28 SpindleForAluminumHousing.FCStd224.45K
214软件图标28 PerfBoardAssembly.FCStd3.15M
215软件图标28 RS422BoardAssembly.FCStd250.43K
216软件图标28 14PinDIP.FCStd200.33K
217软件图标28 15PosSocketStrip.FCStd89.52K
218软件图标28 2PosSmallTerminalBlock.FCStd219.44K
219软件图标28 3PosSmallTerminalBlock.FCStd334.88K
220软件图标28 3PosTerminalBlock.FCStd360.02K
221软件图标28 ArduinoNano.FCStd2.34M
222软件图标28 PerfBoard40x60.FCStd11.84K
223软件图标28 PerfBoard60x80.FCStd11.79K
224软件图标28 RS422Board.FCStd457.45K
225软件图标28 ER20SpindleAssembly.FCStd722.77K
226软件图标28 6001Bearing.FCStd33.62K
227软件图标28 60Tooth3MPulley.FCStd307.71K
228软件图标28 8mmEndMill.FCStd511.16K
229软件图标28 ER20ColletHolder.FCStd122.97K
230软件图标28 Housing.FCStd71.15K
231软件图标28 StopCollar.FCStd112.92K
232软件图标28 XL20Pulley.FCStd31.18K
233软件图标28 ATCAngularContactBearingClamp.FCStd40.90K
234软件图标28 ATCAngularContactBearingSpacer.FCStd23.96K
235软件图标28 ATCBackPlate.FCStd631.65K
236软件图标28 ATCBearingSpacer.FCStd25.26K
237软件图标28 ATCBottomPlate.FCStd151.27K
238软件图标28 ATCColletChuckMount.FCStd856.22K
239软件图标28 ATCFacePlate.FCStd1.57M
240软件图标28 ATCFrontPlate.FCStd215.81K
241软件图标28 ATCLeadNut.FCStd146.81K
242软件图标28 ATCLeadNutGuideBar.FCStd24.42K
243软件图标28 ATCLockingPin.FCStd14.33K
244软件图标28 ATCPinBlock.FCStd50.13K
245软件图标28 ATCPinGuideBlock.FCStd22.34K
246软件图标28 ATCPinLink.FCStd17.99K
247软件图标28 ATCSideA.FCStd139.46K
248软件图标28 ATCSideB.FCStd462.88K
249软件图标28 ATCThrustBearingPlate.FCStd45.44K
250软件图标28 ATCTopPlate.FCStd216.88K
251软件图标28 BallscrewFixedEndSpacer.FCStd23.18K
252软件图标28 BallscrewFloatingEndSpacer.FCStd20.11K
253软件图标28 BaseACMEGuideAngle.FCStd47.15K
254软件图标28 BaseACMENutMountAngle.FCStd58.41K
255软件图标28 BaseACMENutMountSpacer1.FCStd27.52K
256软件图标28 BaseMotorMountPlate.FCStd123.80K
257软件图标28 BaseMotorMountPlateAngle.FCStd43.92K
258软件图标28 BaseSaddleGuidePlate.FCStd57.29K
259软件图标28 BaseSaddlePlate.FCStd194.91K
260软件图标28 BaseSaddlePlate2.FCStd135.45K
261软件图标28 BaseSaddleStepperMountPlate.FCStd62.63K
262软件图标28 BLDCMotorMountAngle.FCStd104.41K
263软件图标28 BrakeCaliper.FCStd1.73M
264软件图标28 ConcreteBase.FCStd63.36K
265软件图标28 CrossSlideACMENutMountAngle.FCStd62.36K
266软件图标28 CrossSlideLeadScrewGuidePlate.FCStd49.84K
267软件图标28 CrossSlideMotorMountPlate.FCStd118.89K
268软件图标28 CrossSlidePlate.FCStd83.61K
269软件图标28 CrossSlidePlate2.FCStd332.29K
270软件图标28 CrossSlideRailSpacer.FCStd28.02K
271软件图标28 CrossSlideVerticalBracePlate.FCStd45.65K
272软件图标28 DiscBrakeArmature.FCStd28.78K
273软件图标28 DiscBrakeArmatureHolder.FCStd99.20K
274软件图标28 DiscBrakeCaliperArm.FCStd35.24K
275软件图标28 DiscBrakeCaliperPivotBase.FCStd34.13K
276软件图标28 DiscBrakeCaliperPivotRiser.FCStd46.39K
277软件图标28 DiscBrakeDisc.FCStd24.95K
278软件图标28 DiscBrakeMagnetHolder.FCStd63.20K
279软件图标28 DiscBrakePadHolder1.FCStd85.76K
280软件图标28 DiscBrakePadHolder2.FCStd56.99K
281软件图标28 ElectronicsMountAngle.FCStd6.44M
282软件图标28 EncoderHeadstockPulley.FCStd28.59K
283软件图标28 EncoderMount.FCStd88.11K
284软件图标28 EndBeltCoverAngle.FCStd93.11K
285软件图标28 HeadstockRiser.FCStd54.35K
286软件图标28 HeadstockRiserBase.FCStd49.67K
287软件图标28 HeadstockRiserGusset.FCStd22.83K
288软件图标28 HeadstockRiserTop.FCStd32.85K
289软件图标28 LeadScrewCoverAngle.FCStd18.38K
290软件图标28 SpindleMotorMountPlate.FCStd51.80K
291软件图标28 SteelBase.FCStd115.54K
292软件图标28 StopBlock.FCStd25.42K
293软件图标28 TailStockBasePlate.FCStd114.99K
294软件图标28 TailStockRiserPlate1.FCStd79.95K
295软件图标28 TailStockRiserPlate2.FCStd100.28K
296软件图标28 TailStockRiserPlate3.FCStd41.39K
297软件图标28 TailStockRiserPlate4.FCStd54.37K
298软件图标28 TailStockRiserPlate5.FCStd45.27K
299软件图标28 ZCrossSlidePlate.FCStd114.23K
300软件图标28 ZMotorMountPlate.FCStd108.03K
301软件图标28 ZNutAngleMountPlate.FCStd236.67K
302软件图标28 ZNutMountAngle.FCStd78.86K
303软件图标28 ZNutSpacer.FCStd21.41K
304软件图标28 ZPlate.FCStd78.95K

机械资料库

工程师必备！

机械面试题库—工程师月薪过万的秘籍

更多▸

机械图纸下载—海量图纸助力设计创新

更多▸

设计资料库—海量资料简化设计

更多▸
